| model |
Z6150ZLCZ-1 |
Z6150ZLCZ-2 |
Z6150ZLCZ-3 |
Z6150ZLCZ-4 |
Z6150ZLCZ |
Z6150ZLCZ-5 |
Z6150ZLCZ-6 |
Z6150ZLCZ-7 |
Z6150ZLCZ-8 |
Z6150ZLCZ-9 |
Z6150ZLCZ-10 |
Z6150ZLCZ-11 |
Z6150ZLCZ-12 |
Z6150ZLCZ-13 |
Z6150ZLCZ-14 |
Z6150ZLCZ-15 |
| type |
straight,four-stroke,direction injection, turbo-charging,air inter cooling |
| NO.of cylinders |
6 |
| bore/stroke(MM) |
150/190 |
| compression ratio |
14.5 |
| piston displacement(L) |
20.15 |
| Rated speed(r/min) |
1000 |
1200 |
1500 |
| continuous output(KW) |
147 |
164 |
184 |
202 |
220 |
240 |
197 |
221 |
242 |
265 |
288 |
246 |
276 |
303 |
331 |
360 |
| mean effective pressure(Mpa) |
0.875 |
0.977 |
1.096 |
1.203 |
1.31 |
1.429 |
0.977 |
1.096 |
1.203 |
1.315 |
1.429 |
0.977 |
1.096 |
1.203 |
1.314 |
1.429 |
| mean piston speed(m/s) |
6.33 |
7.6 |
9.5 |
| minimum steady speed under load(r/min) |
400 |
540 |
670 |
| fuel oil consumption ratio(g/kw.h) |
200 |
| lube oil consumption ratio(g/h) |
250 |
| rotation direction of crankshaft |
to look from the flywheel side to the free side, to turn left is counter-clokewise,1-5-3-6-2-4 |
| starting method |
electric motor |
| cooling mode |
closed water cooling |
| lubricating method |
pressure lubricating |
| height of lifting piston from crankshaft(mm) |
1120 |
| overall dimension(mm) |
2000*1156*1635 |
| net weight(kg) |
2500 |
