| model |
5210ZLC-1 5210ZLCZ-1 |
5210ZLC-2 5210ZLCZ-2 |
5210ZLC-3 5210ZLCZ-3 |
5210ZLC-4 5210ZLCZ-4 |
5210ZLC-5 5210ZLCZ-5 |
5210ZLC-6 5210ZLCZ-6 |
5210ZLC-7 5210ZLCZ-7 |
| type |
straight,four-stroke,supersharging,air inter cooling,irreversible,air inter cooling |
| NO.of cylinders |
5 |
| bore/stroke(MM) |
210/290 |
| Rated speed(r/min) |
600 |
600 |
720 |
750 |
750 |
830 |
860 |
| continuous output(KW) |
330 |
350 |
440 |
500 |
550 |
613 |
662 |
| power per hour |
363 |
385 |
484 |
550 |
605 |
674 |
728 |
| mean effective pressure(Mpa) |
1.31 |
1.39 |
1.46 |
1.59 |
1.75 |
1.76 |
1.84 |
| mean piston speed(m/s) |
5.8 |
5.8 |
6.96 |
7.25 |
7.25 |
8.02 |
8.31 |
| minimum steady speed under load(r/min) |
240 |
240 |
288 |
300 |
300 |
332 |
344 |
| fuel oil consumption(g/kw.h) |
202（heavy fuel+5%） |
| lube oil consumption(g/kw.h) |
≤1.6 |
| rotation direction of crankshaft |
viewed from flywheel side:the engine turned right is clockwise,the engine turned left is counterclockwise |
| starting method |
air motor starting |
| cooling mode |
closed wter cooling |
| lubricating method |
pressure lubricating |
| height of lifting piston from crankshaft(mm) |
1785 |
| overall dimension(mm) |
starboard engine:2970*1425*2230 larboard:3150*1425*2230 |
| net weight(kg) |
8100 |
