| model |
LB6250ZLC LB6250ZLCZ |
LB6250ZLC-1 LB6250ZLCZ-1 |
LB6250ZLC-2 LB6250ZLCZ-2 |
LB6250ZLC-3 LB6250ZLCZ-3 |
LB6250ZLC-4 LB6250ZLCZ-4 |
LB6250ZLC-5 LB6250ZLCZ-5 |
LB6250ZLC-6 LB6250ZLCZ-6 |
LB6250ZLC-9 LB6250ZLCZ-9 |
LB6250ZLC-10 LB6250ZLCZ-10 |
LB6250ZLC-11 LB6250ZLCZ-11 |
LB6250ZLC-12 LB6250ZLCZ-12 |
LB6250ZLC-13 LB6250ZLCZ-13 |
| type |
straight line,foue-stroke,directinjection,supercharged,air intercooling irreversible |
| NO.of cylinders |
6 |
| bore/stroke(MM) |
250/320 |
| Rated speed(r/min) |
600 |
650 |
750 |
825 |
750 |
500 |
| continuous output(KW) |
662 |
692 |
588 |
750 |
882 |
662 |
1000 |
1103 |
750 |
1103 |
735 |
610 |
| resolution per hour,power per hour |
62/729 |
620/762 |
620/647 |
671/825 |
774/791 |
774/729 |
774/1100 |
774/1213 |
774/825 |
852/1213 |
774/809 |
515/671 |
| mean effective pressure(Mpa) |
1.405 |
1.469 |
1.249 |
1.469 |
1.498 |
1.124 |
1.698 |
1.872 |
1.273 |
1.702 |
1.248 |
1.553 |
| mean piston speed(m/s) |
6.4 |
6.9 |
8 |
8.8 |
8 |
5.3 |
| minimum steady speed under load(r/min) |
240 |
260 |
300 |
330 |
300 |
200 |
| fuel oil consumption(g/kw.h) |
200 |
| lube oil consumption(g/kw.h) |
1.6 |
| rotation direction of crankshaft |
the left engine turns right,the right engine resolves right.to look from the flywheel side,to turn right is clockwise. |
| the left engine turns left,the right engine resolves left. To look from the flywheel side to the free side,to turn left is counter-clockwise |
| starting method |
air motor starting |
| cooling method |
closed water cooling |
| lubricating method |
pressure lubricating |
| height of lifting piston(mm) |
2010 |
| overall dimension(mm) |
4143*4500*2567(reference dimensions,take the drawing as standard) |
| net weight(kg) |
13500 |
