| model |
LB8250ZLC LB8250ZLCZ |
LB8250ZLC-1 LB8250ZLCZ-1 |
LB8250ZLC-2 LB8250ZLCZ-2 |
LB8250ZLC-3 LB8250ZLCZ-3 |
LB8250ZLC-4 LB8250ZLCZ-4 |
LB8250ZLC-5 LB8250ZLCZ-5 |
LB8250ZLC-6 LB8250ZLCZ-6 |
LB8250ZLC-7 LB8250ZLCZ-7 |
LB8250ZLC-8 LB8250ZLCZ-8 |
| type |
straight line,foue-stroke,directinjection,supercharged,air intercooling irreversible |
| NO.of cylinders |
8 |
| bore/stroke(MM) |
250/320 |
| Rated speed(r/min) |
600 |
750 |
700 |
650 |
750 |
600 |
| continuous output(KW) |
882 |
1103 |
1177 |
1030 |
735 |
1213 |
1324 |
1470 |
1030 |
| resolution per hour,power per hour |
620/970 |
774/1213 |
774/1295 |
774/1133 |
671/809 |
774/1334 |
774/1456 |
774/1617 |
620/1133 |
| mean effective pressure(Mpa) |
1.405 |
1.405 |
1.498 |
1.405 |
1.08 |
1.544 |
1.686 |
1.872 |
1.639 |
| mean piston speed(m/s) |
6.4 |
8 |
7.5 |
6.9 |
8 |
6.4 |
| minimum steady speed under load(r/min) |
240 |
300 |
280 |
360 |
300 |
240 |
| fuel oil consumption(g/kw.h) |
200 |
| lube oil consumption(g/kw.h) |
1.6 |
| rotation direction of crankshaft |
the left engine turns right,the right engine resolves right.to look from the flywheel side,to turn right is clockwise. |
| the left engine turns left,the right engine resolves left. To look from the flywheel side to the free side,to turn left is counter-clockwise |
| starting method |
air motor starting |
| cooling method |
closed water cooling |
| lubricating method |
pressure lubricating |
| height of lifting piston(mm) |
2010 |
| overall dimension(mm) |
5104*1500*2567(reference dimensions,take the drawing as standard) |
| net weight(kg) |
17900 |
