| Model |
6300C 6300DZC 6300CZ 6300DZCZ |
|
6300ZC 6300ZDZC 6300ZCZ 6300ZDZCZ |
|
6300ZLCA 6300ZLDZCA 6300ZLCZA 6300ZLDZCZA |
|
| Type |
four-stroke,direction injection,reversible or irreversibel,supercharged or unsupercharged,air inter cooling or uninter cooling |
| NO.of cylinders |
6 |
| Bore/stroke(mm) |
300/380 |
| Rated speed(r/min) |
400 |
400 |
500 |
| Continuous output(kw) |
294 |
441 |
551 |
| Resolution per hour,power per hour |
413/324 |
413/485 |
516/606 |
| Mean effective pressure(Mpa) |
0.547 |
0.824 |
0.822 |
| Mean piston speed(m/s) |
5.07 |
5.07 |
6.33 |
| Minimum steady speed under load(r/min) |
160 |
160 |
200 |
| Fuel oil consumption(g/kw.h) |
215 |
| Lube oil consumption(g/kw.h) |
1.6 |
| Rotation direction of crankshaft |
To look from the flywheel side to the free side,to turn right is clockwise,turn left is counter-clockwise |
| Starting method |
Compressed air starting |
| Cooling method |
Closed or opend water cooling |
| Lubricating method |
Pressure lubricating&oiling |
| Height of lifting piston from crankshaft(mm) |
2120 |
| Overall dimension(mm) |
3640*1150*2555 |
3894*1150*2555 |
| Net weight(kg) |
9300 |
9800 |
