| Model |
8300C 8300DZC 8300CZ 8300DZCZ |
8300ZLCA 8300ZLDZCA 8300ZLCZA 8300ZLDZCZA |
8300ZLCA-1 8300ZLDZCA-1 8300ZLCZA-1 8300ZLDZCZA-1 |
8300ZLCA-2 8300ZLDZCA-2 8300ZLCZA-2 8300ZLDZCZA-2 |
8300ZLCA-3 8300ZLDZCA-3 8300ZLCZA-3 8300ZLDZCZA-3 |
8300ZLCA-4 8300ZLCZA-4 |
| Type |
four-stroke,direction injection,reversible or irreversibel,supercharged or unsupercharged,air inter cooling or uninter cooling |
| NO.of cylinders |
8 |
| Bore/stroke(mm) |
300/380 |
| Rated speed(r/min) |
450 |
500 |
600 |
| Continuous output(kw) |
441 |
735 |
808 |
808 |
882 |
1103 |
| Resolution per hour,power per hour |
465/485 |
465/808 |
465/889 |
516/889 |
516/970 |
619/1213 |
| Mean effective pressure(Mpa) |
0.547 |
0.912 |
1.003 |
0.902 |
0.985 |
1.026 |
| Mean piston speed(m/s) |
5.7 |
6.333 |
7.6 |
| Minimum steady speed under load(r/min) |
180 |
200 |
240 |
| Fuel oil consumption(g/kw.h) |
215 |
210 |
| Lube oil consumption(g/kw.h) |
1.6 |
| Rotation direction of crankshaft |
to look from the flywheel side to the free side,to turn right is clockwise,turn left is counter-clockwise |
| Starting method |
compressed air starting |
| Cooling method |
closed or opend water cooling |
| Lubricating method |
pressure lubricating&oiling |
| Height of lifting piston from crankshaft(mm) |
2120 |
| Overall dimension(mm) |
4695*1288*2555 |
4810*1150*2555 |
4810*1150*2555 |
4960*1288*2630 |
| Net weight(kg) |
12000 |
12500 |
12500 |
12500 |
12500 |
13500 |
